Cloth and garments

botrail can put a piece of cloth in a cell — a T-shirt or a plain sheet on a table — and let the robots' grippers handle it: pinch a cuff, turn a sleeve over, carry a hem across, hand a corner from one arm to the other. The cloth is a simulated shell with its own contact against itself, the table and what the grippers hold, and its motion rides the baked timeline like everything else: the studio plays it, the USD recording carries it, and its positions are there to assert on.

examples/cloth/tshirt_fold_demo.py: two UR5e with Robotiq 2F-85 turn the sleeves of a child's T-shirt in and fold the hem onto the shoulders. The amber dots are the vertices a gripper holds.

What it answers, and what it does not

The cloth is simulated after the bake, against the finished cycle. Each gripper's tool point follows its robot through the cycle and holds cloth while a signal is on. The cloth never pushes a robot back and the robots plan as if it were not there, so the cycle time, the reach and the interlocks are exactly those of the cell without cloth. What the cloth adds is where the fabric ends up.

Question	Confidence
Does each hand reach the cuff, the corner, the fold line — and how long is the cycle?	certain — the ordinary reach and timing of the cell
Does the taught fold leave the garment folded: footprint, which edge lies where, what overlaps what?	high — this is what the shell and its contact are for
Does a flap stretch, snag or get dragged by the way it is carried?	high for the geometry of the carry; the cloth's stiffness is one fabric's
Does the hand really hold the cloth: slip, pinch force, a missed grasp?	not modeled — a grasp is ideal: the vertices near the tool point are taken
Does the cloth hang off the table's edge, or catch on a fixture?	not modeled — the support is a level plane, and only a gripper's pad pushes cloth
Is the robot loaded by the cloth?	not modeled — the coupling is one way

Put a cloth in the cell

import botrail as bt

table = bt.parts.table(scene, "table", size=(0.8, 0.84, 0.72))   # adds the frame table/top
shirt = bt.cloth.tshirt("shirt", on="table/top", yaw=1.5708)     # the hem at -x, the shoulders at +x

marks = bt.cloth.landmarks(scene, shirt)       # {"cuff_left": (x, y, z), ...} and frames shirt/cuff_left, ...
# ... teach the arms against the landmarks; set a signal where a gripper closes ...

bt.cloth.add(scene, shirt, grippers=[
    bt.cloth.gripper("grip_north", robot="north", radius=0.05, compliance=0.02, soften=3),
    bt.cloth.gripper("grip_south", robot="south", radius=0.05, compliance=0.02, soften=3),
])
timeline = scene.simulate_sequence("fold")      # the cloth rides every bake from here on

A cloth lies flat on a level support. on= names the frame it lies on — a table's <name>/top — which gives its centre, the support's height and its heading; position=(x, y, z) does the same without a frame. At yaw=0 the width runs along +x and the length (a T-shirt's hem to its shoulders) along -y.

Cloth	Made with	Landmarks
T-shirt	bt.cloth.tshirt(name, body=(0.50, 0.70), sleeve=(0.22, 0.20), layers="sewn" \| "single", neck="notch" \| "round", seams="shared" \| "stitched")	cuff_left/right, hem_left/right/center, shoulder_left/right, underarm_left/right, neck_front/back, chest
Sheet	bt.cloth.sheet(name, (width, length))	corner_nw/ne/sw/se, edge_n/s/w/e, center (north is +y, east +x at yaw=0)

bt.cloth.landmarks returns where those points lie before anything moves the cloth and registers each as a frame, so a motion or an IK target can be taught against shirt/cuff_left like against any other frame. Nothing is simulated for it.

bt.cloth.add registers the cloth on the cell: every bake after it — a simulate_sequence call, or the studio's simulate button — is followed by the cloth's simulation, and the timeline that comes back carries its track. bt.cloth.remove(scene, name) takes it out again. To try cloth settings on a cycle that is already baked, bt.cloth.animate(scene, timeline, cloth, grippers) runs one pass and returns the timeline with the track, leaving the cell as it was.

Grippers

A gripper is a signal and a tool point. The tool point is the robot's TCP, the tip of group= (one arm of a dual-arm robot) or the frame of link=. While the signal is on, the gripper holds:

• Closing takes the cloth vertices within radius of the tool point, through every layer — a pinch at a cuff lifts both layers of the sleeve. A gripper that closes with no cloth in reach holds nothing, and the track says so (warnings).
• A hand-over is a second gripper closing where the first one holds: it takes the whole patch over without the cloth being let go, and the first gripper opening afterwards drops nothing.
• Opening lets go. The cloth keeps the velocity it had.

compliance (m/N) decides how the patch is held. 0 pins it to the gripper. A positive value holds each vertex on a spring, which is what a flap folded by two hands needs: two rigid holds fight each other through the cloth as the flap turns, and the solver gives up; 0.02 is what a T-shirt's hem takes. soften=n weakens the hold tenfold per cloth step over the last n steps before the gripper opens, so a taut flap settles onto what is under it instead of snapping free.

pad=(x, y, z) gives the gripper a box, in its tool frame, that pushes cloth it does not hold — a bar smoothing a sheet, a finger nudging an edge. Without one a gripper passes through cloth. The cloth a gripper holds never collides with its own pad.

The gripper's state is read at the cloth's sample times (every step, 0.1 s by default). A signal pulse shorter than a step between two samples is not seen, so give a grasp a beat: close, wait a few tenths, then move.

Reading the result

track = timeline.cloth("shirt")

track.position("hem_left", timeline.duration)   # where a landmark ended up
track.positions(12.0)                           # every vertex at t = 12 s
track.held(12.0)                                # the vertices a gripper holds then
track.failure                                   # None, or (time, reason) if the cloth stopped
track.warnings                                  # a gripper that closed on nothing, a step taken in parts

timeline.export_usd("fold.usda", fps=30)        # the cloth is a Mesh with time-sampled points

A track is sampled on the cloth's own clock — one sample per cloth step while it moves, the two ends only of a span in which it lies still — and positions blends between the samples around the time asked for, as the studio does. The studio draws the cloth as a mesh and the held vertices as amber dots.

If the solver rejects a step — a flap landing hard on the layers under it, a gripper pressing the patch it holds into the table — the pass retries it in halves, down to eighths of a step, and says so in warnings. If an eighth is rejected too it stops there: the bake still succeeds, the track ends at that time and holds its last state, and track.failure says when and why.

Teaching a fold

The demo's fold is the one a person makes on a table, and the things it has to get right are about how cloth is carried:

• A fold is a turn. The hand carries its patch on an arc about the fold line, so the flap stays as long as it is. A straight carry stretches the flap or drags the garment along.
• Let go above, not on. The turn stops a few centimetres above the cloth it lands on and the flap drops the rest of the way. A hand that carries the patch down into the layer beneath it presses cloth into cloth.
• Two hands on one flap hold it on springs, and let go softly (compliance, soften).
• The crease travels. Nothing holds the garment down, so the fold line creeps as the flap comes over and the flap lands twice that far beyond where a fixed hinge would put it. Set the hinge back by the creep, read off the first bake — the way a fold is taught on a real cell.
• Go slowly. The demo turns a 25 cm flap over in eight seconds. The cloth's step is 0.1 s; a hand that moves a held patch several centimetres per step asks more of the solver than it gives.

Resolution, cost and determinism

spacing is the mesh cell. 0.02 m is what the shell is qualified at: the demo's child's T-shirt is about a thousand vertices and takes about a minute of cloth simulation for its 38 s cycle; an adult shirt (2200 vertices) several minutes. A coarser mesh is not a quicker look at the same fold: cells wider than the cloth's natural crease cannot fold at a seam, so a sleeve turned over drags the body's side with it. Coarse meshes are for tests of plumbing, not of folds.

The pass runs on four threads and is deterministic on one machine: the same cell bakes the same cloth. Debug builds keep the cloth solver optimized, so a maturin develop build simulates cloth at the same speed as a release one.

Limits

• The support is a level plane at the height the cloth was laid on: cloth does not fall off a table's edge, and obstacles of the scene do not collide with it. Robots pass through cloth except for a gripper's pad.
• Grasps are ideal. There is no pinch force, no slip and no force on the robot.
• One fabric: a plain cotton jersey's weight, thickness and stiffness, with thickness, density and friction to adjust. Cloths do not collide with each other.
• A cloth is part of the session, not of the project file: save_project does not write it, and a cell reloaded from a project needs its bt.cloth.add again. The studio draws a cloth in the playback of a bake; it is not an object of the scene tree that can be selected or moved.
• A streamed physics bake from the studio (the physics toggle) does not include cloth; the ordinary simulate button and every Python bake do.
